The DX-D40C incorporates the latest in DR technology and is
ideal for the busy hospital situation with fast workflow,
significantly increasing through put, whilst providing exceptional
resolution
The AGFA DX-D 40C features auto-triggering technology, allowing
its use with any working x-ray generator with no synchronisation
needed. The DX-D40C can be used in a radiography room for the
majority of x-rays, but it can also be moved on a mobile platform,
to the operating theatre if imaging is required during orthopaedic
operations.
Featuring Caesium (CsI) technology, this system offers the highest
image quality while also requiring lower exposures than many other
CR and DR systems.
AGFA DX-D 40C Wireless DR
Agfa's field-leading Caesium Iodide AED plate featuring the newly updated MUSICA 3 image processing software is the industry standard for high resolution small animal imaging.
MUSICA 3 - tuned for small animal radiography
Agfa's new "gold standard" MUSICA 3 image processing software has been developed for veterinary radiography optimising small animal images. Exam-independent, MUSICA 3 ensures outstanding image quality with the high contrast detail, Agfa is renowned for.
NX3 Ultra Fast workflow - maximum speed and ease of use
The DX-D40C, features Agfa's veterinary dedicated NX3 workstation software, combining the highly efficient and optimised workflow of the NX image identification and quality control tool. The NX3 veterinary specific worklist is fully DICOM compatible and enables fast sequence of images in an examination. Fast set up times and ease of use, further speed workflows.
TESTIMONY
Dick White Referrals, which is the world's largest imaging service in private veterinary practice, conducting over 10,000 imaging examinations each year, were the first UK veterinary practice to take on the system in mid 2015 and have found it to be invaluable to their busy operation.
"The AGFA DX-D 40C Wireless DR system has drastically changed how we run our busy department.
A limiting factor in our patient-throughput was the significant wait time between the exposure and having the corresponding image displayed on the monitor. No longer do we have to wait 3 minutes or more to know if a view needs to be repeated. This wait time can quickly add up when having to obtain several repeat views.
Thanks to this investment we are able to reduce the time spent in the x-ray room by an estimated 30% per patient, resulting in 3-5 more patients on any given day.
The image quality is also superior to our previous CR system, but above all, images are always free of previously very common screen artefacts."
Dr Olivier Taeymans DVM, PhD, DipECVDI, MRCVS
Head of Diagnostic Imaging, Dick White Referrals
............................................................................................................................................
"The AGFA DX-D 40C is a very user friendly system that's easy to work with and the speed and the quality of the machine is superb.
The cases each day that we are able to work through have increased by a significant amount.
I love this machine and have said that if it leaves the practice, so will I."
Tammy Robinson RVN
Senior Veterinary Radiographer, Dick White
Referrals
If you are interested in upgrading to the AGFA wireless DR system,
please contact CelticSMR to arrange a no obligation 5 day trial of
the system at your practice so you can compare the performance with
your existing CR system - see the difference in resolution, speed
and income generation
We are able to offer generous buy back terms for your existing CR
system - whatever the age or model
TECHNICAL SPECIFICATIONS
Detector
Detector type: Amorphous Silicon with TFT Conversion
screen: CsI and GOS
Pixel pitch: 140 μm
Active pixel matrix: 2560 x 3072 pixels Active area
size: 358.4 mm x 430.1 mm Effective pixel matrix:
- CsI: 2548 x 3060
- GOS: 2560 x 3072
Effective area:
- CsI: 356.7 mm x 428.4 mm
- GOS: 358.4 mm x 430.1 mm Grayscale: 14 bit
Spacial Resolution: Min. 3.5 lp/mm Outer
dimensions:
384 mm × 460 mm × 15 mm (ISO 4090) Weight:
- CsI: 3.4 kg
- GOS: 3.3 kg
Wireless data transmission:
IEEE 802.1111a/b/g/n, 2.4 GHz/5 GHz, Energy Range
Standard: 40 - 150 kVp
Environmental Requirements
Operation
Temperature: +10 ~ +35° C
Humidity: 30 ~ 85%
(Non-condensing) Atmospheric pressure: 70 ~ 106
kPa Shock: 1.6 G
Vibration: 0.7 G
Drop limits: Max. 700 mm
Storage and
transportation Temperature: -15 ~ +55° C
Humidity: 10 ~ 90%
(Non-Condensing) Atmospheric pressure: 50 ~ 106
kPa Shock: 20 G
Vibration: 0.7 G
Drop limits: Max. 700 mm
Battery Specifications
Type: Lithium Ion Polymer Battery Capacity: 4000
mAh
Nominal Voltage: 7.4V
Charging time: 2 Hours
Operation time:
4 hours (when sleep mode is off) Cycle life: Approx. 500 cycles, Capacity ≥ 80% (100% = 4,000 mAh)
System Control Unit
Power supply
Input: AC100 to 240V, 50/60 Hz, Max. 200VA
Output: DC +24V 3.3A, 80W
Cabling ports
Gigabit Ethernet Ports - 3EA
Power over Ethernet Ports - 2EA Wireless
communications:
IEEE 802.11a/b/g/n (2.4 GHz/5 GHz) Dimensions (W × H ×
D):
300 mm × 235.8 mm × 58 mm, Antenna height - 105 mm
Weight: 2.5 kg
Environmental Requirements
Operation
Temperature: +10 ~ +35° C
Humidity: 30 ~ 85%
(Non-condensing) Atmospheric pressure: 70 ~ 106
kPa
Storage and
transportation Temperature: -15 ~ +55° C
Humidity: 10 ~ 90%
(Non-Condensing) Atmospheric pressure: 50 ~ 106
kPa
